DIESEL AIR-COOLED KD15-225S
Our air-cooled diesel engines are engineered with state-of-art air filters to increase durability, and lengthen service intervals. Couple all of that with the engine’s cast iron cylinder liners and you’ve got a machine that doesn’t know how to quit.
Benefits
- New rugged design for the most extreme conditions
- New integrated sound dampner provide reduced noise levels
- Equipped with a larger air filtration cartridge with increased capacity
- Cyclonic separator with one-way valve for dust discharge
- Lowest fuel consumption
- Lowest oil consumption
- The widest range of accessories
- Highest axial load (2000 N)
Specifications
- Engine type: Four-stroke, aluminum cylinder head, automatic extra fuel starting system
- HP: 3.4 HP (2.5 kW)
- Displacement: 13.4 cu. in. (224 cc)
- Bore: 2.7 in. (69 mm)
- Stroke: 2.4 in. (60 mm)
- Gross Torque: 7.2 ft. lb. (9.8 Nm)
- Compression Ratio: 20:1
- Dry Weight: 61.7 lb. (28 kg)
- Oil Capacity: 1 US qt.(0.9 L)
- Lubrication: Full pressure w/full-flow filter
- Dimensions LxWxH: 14.1 x 10.8 x 16.4 in.
- Emissions Compliance: No Regulations
- Engine Type: Commercial
Equipment Types
- Tiller
- Lawn Mower
- Water Pump (Irrigation)
- Concrete Mixer
- Minidumper
- Compaction Roller
- Vibrating Plate
- Firefighting Pump
- Asphalt Cutter
- Aerial Platform
- Motor Sweeper
- Welder
- Generator Set
- Air Compressor
- Self-Priming Water Pump
- Line Striper
- High Pressure Washer
- Walk-behind Tractor
NOTES:Power (HP) and Torque (ft. lb.) specifications for Kohler general purpose engines are rated pursuant to Society of Automotive Engineers (SAE) J1940 based on gross output testing performed according to SAE J1995 without the air cleaner and muffler. Actual engine power and torque are lower and affected by accessories (air cleaner, exhaust, charging, cooling, fuel pump, etc.), application, engine speed, ambient operating conditions (temperature, humidity and altitude) and other factors. This J1940 / J1995 rating provides consistent measurement to customers who may want to control the intake and exhaust features of the engine.For more information, contact Kohler Co. Engine Engineering Department. Kohler Co. reserves the right to change product specifications, designs and standard equipment without notice and without incurring obligation.Backpressure Limit expressed in Inches of H20 @ 3600 RPM WOTJ1995 power and torque certified by 3rd Party Witness
